Description
Stern/Sega White Star MPU #520-5136-00 MPU/Sound Board.
Rottendog MPUWS STERN/SEGA White Star CPU replaces: #520-5136-00
Compatible with all pre-Atmel #520-5300 games, Apollo 13 (SEGA) through Terminator 3 (Stern)
Not compatible with (ATMEL): Lord of the Rings, Ripley’s Believe it or Not, Elvis, Grand Prix, The Sopranos, NASCAR.
BSMT2000 sound processor Chip-set is not compatible with Atmel chip-set CPU #520-5300 used in later Stern games. The BSMT2000* was used in early production Terminator 3 machines. To identify your chip-set, look for the BSMT2000* 40 pin chip in the center of the cpu.
Board Does not come with Micro processors, game roms, BSMT2000 sound processor. Does include SRAM and 3V Lithium Battery
This board is a replacement for the original Stern Pinball MPU processor & Soundboard. Sega Part #Sega Board #520-5136-00 rev D This board replaces the BSMT2000 version (early).
This board is shipped to our distributors WITHOUT the following chips which can be easily swapped out from the original board.
U21 –
U209 –
U9 –
U6 –
U7 –
U21 –
U36 –
U37 –
Note: Uoo
Some of our distributors may offer fully populated boards that are plug and play.
Game List
- Apollo 13
- Austin Powers
- Godzilla
- Golden Eye
- Harley –
Davidson 1st/2nd - High Roller Casino
- ID4 Independence Day
- Lost in Space
- Monopoly
- NFL
- Roller Coaster Tycoon
- Sharkey’s Shootout
- South Park
- Space Jam
- Starship Troopers
- Stern Playboy 2002
- Striker Extreme
- Terminator 3
- The Lost World Jurassic Park
- The Simpsons Pinball Party
- The Star Wars Trilogy
- The X Files
- Twister
- Viper Night Drivin
Installation instructions:
There are two different EPROM sizes used for the U7 Sound ROM and the W6 jumper needs to match the EPROM size needed for your game. If U7 is a 27C1001 then the jumper at W6 should be installed. Earlier games where U7 is a 27C512 EPROM should remove the jumper at W6 for proper operation.
